ATIANA HAND SIMULATOR

SJA ROBOTICS

Simulation Only | No Physical Hardware Connected

Active Hand
Right
Control Mode
Manual
Tracking
Unavailable
Simulation
Running

3D hand viewer

Loading 3D view…

Drag to orbit, scroll or pinch to zoom. Solid: what ATIANA's first five-servo hand can reach. Gold wireframe: the intended human pose (wrist, thumb opposition and finger spread have no actuator yet).

Camera imitation

camera off

Privacy: the camera starts only when you press Start camera. Video is processed by MediaPipe inside this browser tab; no footage or hand data is uploaded, recorded or stored, and this page makes no network requests other than loading its own files. Press Stop camera (or leave the tab) to release the camera.

no hand landmarks
robot leftUnavailable

Sees: —

robot rightUnavailable

Sees: —

Put a hand in Camera mode to imitate you. When your hand leaves the view or tracking becomes unreliable, the robot hand holds its pose and resumes after half a second of stable tracking. Works best in good light with the whole hand visible.

Hand & control mode

One controller owns each hand. Switching mode decelerates the hand and holds it; the new controller continues from there (no jumps). Stop and emergency stop work in every mode.

Manual finger control

20% → 20%
20% → 20%
25% → 25%
30% → 30%
35% → 35%
30% → 30%
15% → 15%
0° → 0°
0° → 0°
0° → 0°

Gesture library

  • Open palm
    Approximate
  • Closed fist
    Reproducible
  • Thumbs up
    Approximate
  • Pointing
    Approximate
  • Peace sign
    Approximate
  • OK sign
    Simulation only
  • Waving
    Simulation only
  • Pinching
    Approximate
  • Relaxed hand
    Reproducible
  • Custom finger pose
    Reproducible
Sequence:empty

“Simulation only” gestures need a wrist actuator or thumb opposition the five-servo hand does not have; they play on the anatomical (ghost) hand in simulation and are refused on hardware.

Servo targets

right handsimulated · not calibrated

    Cyan: commanded pulse. Green: simulated servo response. Hobby servos report no position or force, so on hardware only the command is known.

    Joint positions · right

    JointAnatomicalMechanismRange
    thumb cmc11.3°10.0°
    thumb mcp6.9°12.2°
    thumb ip0.0°16.0°
    thumb cmc abduction16.5°19.3°
    thumb cmc rotation21.0°24.5°
    index mcp21.2°20.0°
    index pip17.5°21.0°
    index dip4.7°16.0°
    index mcp abduction1.8°1.2°
    middle mcp26.5°25.0°
    middle pip23.3°26.3°
    middle dip9.4°20.0°
    middle mcp abduction0.0°0.0°
    ring mcp31.8°30.0°
    ring pip29.2°31.5°
    ring dip14.1°24.0°
    ring mcp abduction-1.2°-0.8°
    little mcp37.1°35.0°
    little pip35.0°36.8°
    little dip18.8°28.0°
    little mcp abduction-2.7°-1.8°
    wrist flex0.0°0.0°
    wrist deviation0.0°0.0°
    wrist rotation0.0°0.0°

    Amber mechanism values differ from the intended anatomical pose.

    Event log
